Q Switch ND YAG laser for colorized tattoo removal & pigmentation removal best laser pigmentation removal machine

Treatment Principle

The machine utilizing the explosive effect of the ND: YAG LASER, the laser permeates the epidermis into the dermis and takes effect on pigment mass and is absorbed by pigment. Since the laser pulses is extremely short in nanosecond and comes with super high energy, the pigment mass would swell quickly and break into small pieces, which will be eliminated through metabolism. In this case, the pigments become lighter gradually and finally disappear.

Technical Parameters

Basic parameters:

1. Dimensions (without articulated arm, Width×Length×Height): 370 mm ×957 mm ×992 mm；

2. Total weight(include articulated arm): <80kg;

3. Power input: 1200VA;

4. Rated current of leakage:10A;

5. Repetition Rate: 1-5Hz;

6. Nominal ocular hazard distance: NOHD 3.3km,

Note: operation shall be in a closed room and make sure to wear goggles!

7. cooling system: built-in closed circulating water cooling;

Photoelectric property:

1. Laser output mode: Q-switched pulse;

2. Laser wavelength: 1064/532nm；

3. Pulse Duration: 5ns±1ns;

4. Maximum pulse energy in the end of articulated arm: 500mJ@1064nm；200mJ@532nm；

5. Error oflaser output energy: ≤±20%;

6. Spot size:2-10mm continuously adjustable, error less than ±20%;

7. aiming beam wavelength: 635 nm; output power Pc shall be 0.1mW≤Pc≤5mW;

8. The distance betweenspot center and aiming beam center ≤0.5mm;

Application

Tattoo Removal, Treatment of Vascular Lesions, Treatment of Pigmented Lesions, Incision, Excision, Ablation, Vaporization of Soft Tissue for General Dermatology.

Sincoheren is a senior medical and aesthetic equipment supplier founded in 1999.Over the past 19 years,Sincoheren has been focusing on developing various medical and beauty equipment.Our headquarter is in Zhongguancun,Haidian District,Beijing.

As a high-tech enterprise,Sincoheren possesses the certificate for producing and selling medical instruments and owns independent intellectual property rights.In the company,we set R&D department,sales department,production department,quality inspection department,and general administration department,etc.Sincoheren possesses large plants covering 5000㎡,among which the office buildings take 2/5.We are now staffed by 300 people.Contributed to the powerful technique.abd first-class service,Sincoheren is rapidly tapping into th international market in recent years and our annual sales grows to hundreds of billions yuan.

Successively in the past 19 years,Sincoheren has developed medical laser skin treatment instrument(Nd Yag Laser),intence pulsed light medical device,RF body slimming machine,tattoo laser removal machine,laser hair removal device,fractional CO2 laser equipment,coolplas fat freezing machine,and HIFU machine,Raliable qualitya and considerate after sales service is why we are so popular among partners.

Monaliza Q-switched Nd:YAG laser therapy instrument,one of the brands of Sincoheren,is the first laser skin treatment equipment that gets the CFDA certificate in China.
